Undercarriage Parts for Hitachi ZX470-5A Excavator (Track)

Pitch: 8.50
Bolt Hole Diameter: 24mm
Link Height: 129.0mm
Bushing O.D.: 71.4mm

Stock photos provided to us by the manufacturer do not necessarily represent the actual item being purchased. Please refer to the title and description on this page before you place your order.

TRACK CHAIN - SEALED AND GREASED

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-SI873/53	TLA S&G EX400	TLA S&G EX400 quantity	$4,361.59		TLA S&G EX400 quantity
	ITR-UL215H2P53	TLA S&G 3756GLC	TLA S&G 3756GLC quantity	$4,823.96		TLA S&G 3756GLC quantity

SHOES - SINGLE GROUSER

	Part Description	Machine Qty	Cost Each	Select
ITR-KM2230/600	GRSR 1B 3754D	GRSR 1B 3754D quantity	$101.10	GRSR 1B 3754D quantity
ITR-KM2230/710	GRSR 1B 450	GRSR 1B 450 quantity	$126.01	GRSR 1B 450 quantity
ITR-KM2230/900	GRSR 1B 900MM	GRSR 1B 900MM quantity	$166.89	GRSR 1B 900MM quantity

SHOES - DOUBLE GROUSER

	Part Description	Machine Qty	Cost Each	Select
ITR-KM2447/600	GRSR 2B 959J	GRSR 2B 959J quantity	$100.39	GRSR 2B 959J quantity
ITR-KM2447/710	GRSR 2B 28"	GRSR 2B 28" quantity	$120.09	GRSR 2B 28" quantity
ITR-KM2447/760	GRSR 2B 30"	GRSR 2B 30" quantity	$128.96	GRSR 2B 30" quantity

SHOES - TRIPLE GROUSER

	Part Description	Machine Qty	Cost Each	Select
ITR-KM1426/600K	GRSR 3B EX400-2	GRSR 3B EX400-2 quantity	$86.61	GRSR 3B EX400-2 quantity
ITR-KM1426/750K	GRSR 3B PC400	GRSR 3B PC400 quantity	$104.48	GRSR 3B PC400 quantity
ITR-KM1426/800K	GRSR 3B PC300HD	GRSR 3B PC300HD quantity	$117.04	GRSR 3B PC300HD quantity
ITR-KM1426/900K	GRSR 3B PC400	GRSR 3B PC400 quantity	$125.51	GRSR 3B PC400 quantity

RUBBER PAD - CLIP ON - CLIPS TO SHOE

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-RP216/600	RUBBER PAD	RUBBER PAD quantity	$89.38		RUBBER PAD quantity
	ITR-RP216/700	RUBBER PAD	RUBBER PAD quantity	$108.26		RUBBER PAD quantity

TRACK HARDWARE

	Part Description	Machine Qty	Cost Each	Select
ITR-4328034	BOLT, TRACKNote Use with 3B shoes	BOLT, TRACK quantity	$2.35	BOLT, TRACK quantity
ITR-4295784	BOLT, TRACKNote Use with 1B & 2B shoes	BOLT, TRACK quantity	$2.69	BOLT, TRACK quantity
ITR-178-32-11220	NUT, TRACK 24MMNote Preferred for ITR brand chain	NUT, TRACK 24MM quantity	$1.08	NUT, TRACK 24MM quantity
ITR-4295785	NUT, TRACK 24MMNote Optional, may be required on non ITR product	NUT, TRACK 24MM quantity	$1.19	NUT, TRACK 24MM quantity

TRACK GROUP ASSEMBLY CHARGE

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-ASM6	TGA LABOR CHARG	TGA LABOR CHARG quantity	$356.25		TGA LABOR CHARG quantity

TOP CARRIER ROLLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-AT201927	TCR ASSY EX400	TCR ASSY EX400 quantity	$215.11		TCR ASSY EX400 quantity

MOUNTING HARDWARE - TOP CARRIER ROLLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-01010-31860	BOLT, 18X60MM	BOLT, 18X60MM quantity	$1.33		BOLT, 18X60MM quantity
	ITR-01643-31845	WASHER, RLR MNT	WASHER, RLR MNT quantity	$0.30		WASHER, RLR MNT quantity

LOWER ROLLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-LH90	S/F RLR GRP	S/F RLR GRP quantity	$471.56		S/F RLR GRP quantity

MOUNTING HARDWARE - LOWER ROLLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-01011-62210	BOLT, 22X110MM	BOLT, 22X110MM quantity	$2.65		BOLT, 22X110MM quantity

SPROCKETS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-FT3061	SPROCKET EX400	SPROCKET EX400 quantity	$409.70		SPROCKET EX400 quantity

MOUNTING HARDWARE - SPROCKETS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-01010-32270	BOLT, 22MM	BOLT, 22MM quantity	$1.46		BOLT, 22MM quantity
	ITR-3B4514	LOCKWASHER, 7/8	LOCKWASHER, 7/8 quantity	$0.39		LOCKWASHER, 7/8 quantity

FRONT IDLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-9244297	IDLER GRP ZX450	IDLER GRP ZX450 quantity	$1,277.91		IDLER GRP ZX450 quantity

MOUNTING HARDWARE - FRONT IDLERS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-6V3532	BOLT, SPROCKET	BOLT, SPROCKET quantity	$1.45		BOLT, SPROCKET quantity
	ITR-01602-02060	LOCKWASHER	LOCKWASHER quantity	$0.46		LOCKWASHER quantity

TRACK TENSIONING COMPONENTS

	Part Description	Machine Qty	Cost Each	Select
ITR-9244702	TRK ADJ ZX450-3	TRK ADJ ZX450-3 quantity	$2,305.93	TRK ADJ ZX450-3 quantity
ITR-3102854	ZX450-3 SPRING	ZX450-3 SPRING quantity	$790.60	ZX450-3 SPRING quantity
ITR-2051606	YOKE, IDLER	YOKE, IDLER quantity	$1,491.30	YOKE, IDLER quantity
ITR-9155799K	SEAL KIT,ADJSTR	SEAL KIT,ADJSTR quantity	$51.43	SEAL KIT,ADJSTR quantity

CENTER/SEGMENTED TRACK GUIDING GUARDS - MUST CONFIRM CURRENT MACHINE CONFIGURATION

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-8100798	GUARD, TRACK	GUARD, TRACK quantity	$1,008.55		GUARD, TRACK quantity

MOUNTING HARDWARE - CENTER/SEGMENTED TRACK GUIDING GUARDS

Part Number		Part Description	Machine Qty	Cost Each	Cost Extended	Select
	ITR-J932200	BOLT,22 X 100MM	BOLT,22 X 100MM quantity	$9.86		BOLT,22 X 100MM quantity
	ITR-4375092	SPACER, GUARD	SPACER, GUARD quantity	$43.66		SPACER, GUARD quantity
